OnBon BX-5Q0+ Asynchronous Multi Color LED Control Card (Ethernet+USB)

Applications:

With 100M Ethernet port and USB port;
Best price, simple operations, and high performance price ratio;
Widely used in kinds of small LED lintel full color display screen;
The guide of LED lintel full color display screen;

Features:

♦Support 100M Ethernet port, bound with MAC mechanism, no need of IP settings, identify and connect intelligently;
♦Ethernet communication mode support direct link/Ethernet/Internet;
♦Support U disk play;
♦Smart control area, abundant display functions;
♦ Good technicals, best quality, 3.5V-6V wide working voltage, -40°C-80°C working temperature;
♦ Support firmware update;
♦ Support temperature sensor and temperature & humidity sensor;
♦ Support infrared remote control;

BX-5Q+ latest function:

Add high brightness/ high refresh rate mode;
Add the function of refresh rate as to solve the problem of virtual lights;
Add neon area and neon stunt group which with stronger activeness and effect;
Add 8 kinds of graphic display modes on Text/Graphic area;
Easy to operate, with good application test

Technical parameters:

Product name	BX-5Q0+ multi-area asynchronous lintel controller for full color
Products status	The latest 5th generation products, put into the market on December, 2012.
Memory voltage	128MByte
Control area	51240 41648 32064 25680 20896 160128 128*160
Gray scale	256/128/64 grade
Screen types	All kinds of full colors led screen
Software function	Groups cluster management/multi-program editing/multi-area display/multi-language version
Program type	Normal/Shared program
Program quantity	Support 512 programs, each program with 32 areas
Area type	Neon/overlay text/graphic/subtitle/animation/time/clock/timer/temperature/temperature & humidity
Frame mode	The advanced colorful border/area border
Background	Support picture background/animation background
Clock mode	Dial/in Chinese and English/timer (all support multi-groups)
Communication port	Support 100M Ethernet and USB port
Interface	1 nos 50PIN/160 lines
Sensor supported	Temperature/temperature & humidity
Remote control	Select program/lock screen/brightness adjustment/power on & off/screen test
Bright regulation	16 grades brightness, support manual and auto-timing adjustment/remote control
Power on/off	Support auto-timing power on & off/software power on & off/remote control
Working voltage	5V(3.5V-6V wide voltage)
Maximum power	≤2.5W
Working temperature	-40°C~80°C
SDK	Support DLL
Software	LEDshowTW2012
User manual	"5th generation multi-area LED controllers' user manual"
Adapter	For BX-5Q: HUB-Adapter HUB-T75A HUB-T74 HUB-T08
