Magnimage 550DS LED Panel Wall Video Processor

Magnimage 550DS LED Panel Wall Video Processor

  • Model: CLS-Magnimage-550DS
  • 55 Units in Stock
  • Shipping Weight: 8Kg
  • Manufactured by: Magnimage
$690.00

  • Product Details
  • Shipping information
  • Customer Reviews

Magnimage 550DS LED Panel Wall Video Processor

Magnimage 550DS LED panel wall video processor is geared with SDI input. LED-550DS can install two popular sending cards such as Linsn, Novastar, Colorlight, Dbstar, Zdec, etc. The price above does not include the senders. Please order separately if needed---no shipping cost is charged for the 2 senders if buying together.

Features:

1. Supports Fade in/ Fade out and Wipe Functions;

2. Supports EDID management, for pixel to pixel display;

3. Supports double picture function (PIP/POP);

4. Supports dual channels image crop;

5. Supports  Hot backup;

6. Full/ Part Function;

7. Text overlying function;

8. Test pattern output (include 72 test patterns);

9. Two sending cards can be built-in;

10. More convenient operation interface

Specifications:

Input parameters

Input interface

Channel

Standard

AV

2

PAL  NTSC

VGA

2

VESA

DVI

1

VESA(include1080i)

HDMI

1

480I/P  576I/P  720P  1080I/P

DP

1

DisplayPort 1.1

SDI *

1

480I  576I  720P  1080I/P(3G SDI)

Output parameters

Output interface

Channel

Standard

VGA

1

1024x768/60Hz/75Hz/85Hz/100Hz/120Hz    1280x1024/60Hz  1024x1280/60Hz  1440x900/60Hz  1600x1200/60Hz  1600x1200/60Hz-Reduced  1680x1050/60Hz  1920x1080/50Hz  1920x1080/60Hz

2560x816/60Hz  2048x640/60Hz  2304x1152/60Hz  2048x1152/60Hz  1536X1536/60Hz  1920x1200/60Hz

User-defined resolution

DVI

2

DVI loop out

1



SDI * loop out

1

480I  576I  720P  1080I/P(3G SDI)

Note: SDI input is for LED-550DS only

General

Power supply

110V - 240V/AC  50/60HZ

Power consumption

20W

Operating temperature

0-45℃

Humidity

10% - 90%, No condensation

Cabinet Dimension (LxWxH)

485 x 285 x 55 mm

Net weight

2.9Kg

Shipping weight

8Kg

 Model

Model Name

Introduction

LED-550D

Standard type

LED-550DD

Standard type+ 1 extend DVI input

LED-550DV

Standard type+ 1 extend VGA input

LED-550DS

Standard type+ 1 extend SDI input
