Linsn EB901 LED Sending Card Distributor

The Linsn EB901 sending card distributor is designed for LED multi-display or super-large screens. EB901 is the updated model of EB701, which is fully compatible.

Features:

 To minimize signal delay or loosing problem caused by failure of receiving cards or cables;

 Easy to locate the faulty cabinets;

 Keep other led display cabinets working while having maintenance with the defective cabinets.

EB901 works in two ways:

 One distributor: It can have one or two inputs (A/B or A&B ports).

 One output (U or D port) from sending card to splitter A/B port, can be divided into max 9 outputs (A1~A9).

 Two inputs (U and D ports) from sending card to A and B ports, each input is divided into four outputs, that is A input is divided into A1, A2, A3, A4 outputs and B input is divided into B1, B2, B3 and B4 outputs.

2: Two or more distributors work together. One output of sending card to A port of splitter, then splitter B port outputs to another splitter A port, Maximum eight splitters can work together.

On the display connection of LEDstudio / LEDSet:

 Main cable: select the output port of sending card.

 1 No. sender U cable means number one sending card, U port

 4 No. sender U cable means number four sending card, U port

 Four 802 sending cards can be cascaded with the switch on.

 Extension cable: output number of splitter port.

 Under same Main, extension cable starts from 1, then 2, maximum to 9.

 Under different Main, extension cable starts from 1 for each main, maximum to 4.

 Order No.: receiving card order number.

 Within same extension number, order number goes from 1, then 2 and continues to last number.

 With different extension number, each order number starts from 1.

Box Size: 356mm*172mm*44.5mm

Power Supply: 100~240V 50~60Hz 0.6A

Light indicators: blinking green light for signal, red light for power
