Colorlight i6 Multi-purpose LED Receiving Card

Colorlight i6 control card  is COLORLIGHT's special introduced high-end and all-purpose receiver card , featuring a small size with 68*33mm; it is adopt DDR2 SODIMM interface, can be easily integrated into the HUB board or unit plate of LED display, and achieves the high integration of the LED display module, which greatly facilitates the design of the LED display unit panel and structure.

i6 has all the functions of the mainstream receiver card. Besides, it has also developed a series of practical and powerful functions for the high-end display screen, improving the added value of the custom product.

Product Features:

1: Large load capacity of 256*256 pixels for each card;

2: Support smart module, save calibration coefficients and module parameters on module ;

3: Support the receiver card double backup and power supply double backup;

4: Support various freeform display, spherical display, creative display, etc.

5: Support high-precision point-by-point calibration in the Brightness and the chromaticity;

6: Support 32 groups of RGB signal output.

7: Support the cable detection

8: Support cabinet’s temperature, humidity, power supply voltage monitoring and fan rotating control

9: Superior versatile, supporting Gigabit Ethernet, T7 sending cards, Q7 HD transmitter, network video system, etc. all conventional sending equipment

10: Support error detection of LED on module point- by –point ;

11: Support any scan mode from static to 1/32 scan;

12: Wide working voltage range with DC3.3 -6V;
