CL-PAS4-200-4.5A Series LED Panel Power Supply

The CZChenglian CL-PAS4-200 LED display panel power supply series includes CL-PAS4-200-4.5A, CL-PAS4-200-4.5B, CL-PAS4-200-4.5C, CL-PAS4-200-5A, CL-PAS4-200-5B, and CL-PAS4-200-5C.

Model NO: 200W PAS4 series

AC90-264Vac input voltage

CL-PAS4-200-4.5A, DC 4.6V, 0-40A

CL-PAS4-200B-4.5B, DC 4.6V, 0-40A

CL-PAS4-200B-4.5C, DC 4.6V, 0-40A

Input Parameters:

Input Voltage Range: 90～264Vac

Input Frequency Range: 47～63HZ(Typ 50/60)

Max AC Current: <3A, 100Vac, full load

Inrush current: ≤80A, 240V, Full load, 25℃

PF >0.95(AC100~240Vac, full load)

Leakage Current:I/P-O/P:≤0.25mA, I/P-F/G:≤3.5mA (Vin=250Vac 60HZ)

Standby watt<5W

Output Parameters:

Dc Voltage Range: 4.5 V( 5V is available too)

DC output voltage range: 4.2-4.8VDC

Output Current: 40A(input voltage:100～240Vac)

Max power:180W

Ripple & Noise: ≤500mVp-P（@220Vac, rated load,25℃）

Efficiency (Typ): ≥87%（Typ 89%) input Voltage: 230Vac, Rated load,25℃; ≥85%（Typ 86.5%),input voltage: 115Vac, Rated load,25℃

Output Risetime<50mS

Power on delay time<3S

Voltage Tolerance:±2%

Line Regulation: ±1%

Load Regulation:±2%

Protection:

Over voltage protection: 5.2-5.6V

Over current protection: 50-60A

Over temperature protection: 75-90℃, full load 25℃.

Short circuit protection,Hiccup mode, recovers automatically after fault condition is removed

Safety Standards:

UL60950, IEC/EN60950, GB4943.1

EMC: FCC Part 15 B,EN55022(CISSPR22)ClassB,EN61000-3-2,EN61000-3-2

EMI: EN61000-4-2,3,4,5,6,8,11, EN55024 Class A light industry standard (Surge: 4KV)

Hi-pot: I/P-O/P: 3.0KVAC/ 10mA/ 60S , I/P-FG:1.5KVAC/ 10mA/ 60S , O/P-F/G: 500Vdc/10mA/ 60S

Isolation Resistance:I/P-O/P:≥10MΩ@ 500Vdc,I/P-F/G:≥10MΩ@ 500Vdc,O/P-F/G:≥10MΩ@ 500Vdc

Leakage current: I/P-FG: ≤3.5mA , I/P-O/P:≤0.25mA (240Vac/60Hz)

Others:

Working Temperature:-20℃ ～ +70℃

Working Humidity:5%～90%RH

Storage temperature: -40℃～+80℃

Free air convection

Dimension (L*W*H): 145*78*26.8mm

Carton Dimensions: 52*37.5*24CM

Packing:40PCS/21.5KG/0.04CBM, in white paper box

MTBF:50K hours (MIL-HDBK-217F (25℃ )

Products Parameters:

Model NO Drive Mode Output Voltage Output Current Ripple&Noise Full Load Efficiency 115V / 230V

CL-PAS4-200-5A CV 5V±2% 0-40A ≤300mV 86.0% 87.0%

CL-PAS4-200-5B CV 5V±2% 0-40A ≤300mV 86.0% 87.0%

CL-PAS4-200-5C CV 5V±2% 0-40A ≤300mV 86.0% 87.0%

CL-PAS4-200-4.5A CV 4.5V±2% 0-40A ≤300mV 86.0% 87.0%

CL-PAS4-200-4.5B CV 4.5V±2% 0-40A ≤300mV 86.0% 87.0%

CL-PAS4-200-4.5C CV 4.5V±2% 0-40A ≤300mV 86.0% 87.0%
